Product Description
Application
Municipal road drainage, water collection Wells, communities, factories and mining enterprises, where there is rainwater accumulation, to set up drainage pipelines, so that the water will be into the underground , rainwater grating is essential materials for construction projects.
Main Features
| 1. Good toughness. | 2. Strong corrosion resistance. |
| 3. Good plasticity. | 4. High strength. |
| 5. Perfect anti-theft and safety performance. | 6. Low Noice. |
Specification
| Product | Size(W*L*H,mm) | Weight(kg) | Loading Capacity |
| Ductile Iron Gully Grating | 600×700×50 | 80 | C250 |
| 600×600x50 | 50 | C250 | |
| 600×600×35 | 20 | A15 | |
| 552×724×55 | 55 | B125 | |
| 500×500×50 | 37 | D400 | |
| 450×750×50 | 53 | D400 | |
| 450×750×50 | 40 | C250 | |
| 450×750x45 | 45 | C250 | |
| 450×750×40 | 46 | C250 | |
| 450×750x40 | 33 | B125 | |
| 450×750×35 | 27 | B125 | |
| 400×700x45 | 31 | B125 | |
| 400×700x40 | 24 | B125 | |
| 400×600×45 | 29 | C250 | |
| 400×600×40 | 20 | B125 | |
| 400×600×35 | 16 | B125 | |
| 400×500x40 | 29 | C250 | |
| 390×510×50 | 31 | B250 | |
| 380×680×50 | 39 | C250 | |
| 380×680x45 | 29 | C250 | |
| 380×680x40 | 25 | B125 |
